New research has shown how the squirting cucumber achieves efficient seed dispersal through a pressurized launch system, providing insights for bio-inspired applications.
A new study led by the University of Oxford has unraveled a centuries-old scientific mystery: the mechanism behind the squirting cucumber’s explosive seed dispersal. The research, which involved a series of experiments, high-speed videography, image analysis, and advanced mathematical modeling, was recently published in The Proceedings of the National Academy of Sciences (PNAS).
Unveiling the Dispersal Mechanism
The squirting cucumber (Ecballium elaterium, derived from the Greek ‘ekballein,’ meaning to throw out) is named for its explosive method of seed dispersal. When ripe, the ovoid-shaped fruits detach from the stem and eject the seeds explosively in a high-pressure jet of mucilage. This projectile launch, which lasts just 30 milliseconds, propels the seeds at speeds of up to 20 meters per second, allowing them to land as far as 10 meters away—roughly 250 times the length of the fruit.
Until now, the exact mechanism of the squirting cucumber’s seed dispersal – and how this affects its reproductive success – remained poorly understood. In the new study, researchers from the University of Oxford and the University of Manchester conducted a variety of experiments on Ecballium specimens grown at the University of Oxford Botanic Garden.
This included filming the seed dispersal using a high-speed camera (capturing up to 8600 frames per second), measuring fruit and stem volume before and after dispersal, performing indentation tests and CT scans of an intact cucumber, and monitoring the fruit with time-lapse photography in the days leading up to launch. They then developed a suite of mathematical models to describe the mechanics of the pressurized fruit, the stem, and the ballistic trajectories of the seeds.
High-speed color video showing the ejection of seeds by the squirting cucumber (Ecballium elaterium). The video is captured at 10,000 fps, and so is slowed down 400 times. Credit: Dominic Vella
Key Discoveries and Strategic Implications
Using this combined approach, the team elucidated the key components of the plant’s dispersal strategy:
- A pressurized system: In the weeks leading up to seed dispersal, the fruits become highly pressurized due to a build-up of mucilaginous fluid.
- Fluid redistribution: In the days before dispersal, some of this fluid is redistributed from fruit to stem, making the stem longer, thicker, and stiffer. This causes the fruit to rotate from being nearly vertical to an angle close to 45°, a key element needed for a successful seed launch.
- A rapid recoil: In the first hundreds of microseconds of ejection, the tip of the stem recoils away from the fruit, causing the fruit to counter-rotate in the opposite direction.
- Variable launch: Due to the components above, the seeds are ejected with an exit speed and launch angle that depend on their sequence: with subsequent seeds, the exit speed decreases (because the pressure of the now emptying fruit capsule decreases) while the launch angle increases (due to the fruit’s rotation). This causes the initial seeds to reach the furthest distance, with subsequent seeds landing closer. As multiple fruits are distributed around the center of the plant, the overall result is a wide and nearly uniform distribution of seeds covering a ring-shaped area at a distance of between 2 and 10 m from the mother plant.
Together, these components make up a sophisticated seed dispersal system. In particular, the redistribution of fluid from the fruit back into the stem is considered unique within the plant kingdom.
Impact on Plant Survival and Potential Applications
The researchers used the mathematical model to explore the consequences of artificially altering different parameters. This revealed that the squirting cucumber’s seed projection method has been fine-tuned to ensure near-optimal dispersal and the plant’s success over generations.
For instance, making the stem thicker and stiffer resulted in the seeds being launched almost horizontally, since the fruit would rotate less during discharge. This would cause the seeds to be distributed over a narrower area, with fewer likely to survive.
Meanwhile, reducing the amount of fluid redistributed from the fruit to the stem resulted in an over-pressurized fruit, causing the seed to be ejected at higher speeds but at a nearly vertical launch angle. Consequently, the seeds would not be dispersed far enough away from the parent plant, and again, few would survive.
Results of a computed tomography (CT) scan showing the interior organization of the seeds within the fruit of the squirting cucumber. Credit: Elizabeth Evans
Historical Context and Future Directions
Author Dr. Chris Thorogood (Deputy Director and Head of Science at Oxford Botanic Garden) said: “For centuries people have asked how and why this extraordinary plant sends its seeds into the world in such a violent way. Now, as a team of biologists and mathematicians, we’ve finally begun to unravel this great botanical enigma.”
Co-author Dr. Derek Moulton (Professor of Applied Mathematics at the Oxford Mathematical Institute) said: “The first time we inspected this plant in the Botanic Garden, the seed launch was so fast that we weren’t sure that it had actually happened. It was very exciting to dig in and uncover the mechanism of this unique plant.”
According to co-author Dr. Finn Box (Royal Society University Research Fellow, University of Manchester), “This research offers potential applications in bio-inspired engineering and material science, particularly on-demand drug delivery systems, for instance, microcapsules that eject nanoparticles where precise control of rapid, directional release is crucial.”
Ecballium elaterium (pronounced: eck-ball-ee-uhm elaht-eh-ree-uhm) is a member of the gourd family (Cucurbitaceae), which also includes melon, pumpkin, squash, and courgette. The species is native to the Mediterranean, where – thanks to its effective seed-dispersal strategy- it is often regarded as a weed. The plant was described by the ancient Greeks and Romans: naturalist Pliny the Elder (AD 23/24 – AD 79) said: “Unless, to prepare it, the cucumber be cut open before it is ripe, the seed spurts out, even endangering the eyes.”
Reference: “Uncovering the mechanical secrets of the squirting cucumber” by Finn Box, Derek E. Moulton, Dominic Vella, Yuvraj Bhagotra, Tristan Lowe, Alain Goriely and Chris J. Thorogood, 25 November 2024, Proceedings of the National Academy of Sciences.
DOI: 10.1073/pnas.2410420121
