Physicists Discover Hidden Quantum Forces That Could Supercharge Your Devices

Physicists have identified an unprecedented quantum phenomenon that allows precise manipulation of electron spin and magnetization.

This advancement is expected to drive the development of next-generation spintronic technologies, including neuromorphic computing that mimics human brain functions.

The Spintronics Advantage for Faster Electronics

In today’s fast-paced digital world, the demand for greater storage capacity, efficiency, and computing power is constantly growing. To keep up, scientists are exploring the exciting field of spintronics, which has the potential to revolutionize modern electronics.

Unlike traditional electronics, which rely solely on the charge of electrons to process and store information, spintronic devices take advantage of both the charge and the spin of electrons. By assigning binary values to an electron’s spin—up for 0 and down for 1—these devices can achieve faster performance and greater energy efficiency.

Unlocking Quantum Properties

However, to make spintronics a practical reality, researchers must understand the quantum properties of materials at a deeper level. One key factor is spin-torque, which allows electrical currents to control magnetization—a critical function for developing the next generation of data storage and processing technologies.

Researchers at the University of Utah and the University of California, Irvine (UCI), have discovered a new type of spin-orbit torque. A research study, published in Nature Nanotechnology on January 15, 2025, demonstrates a new way to manipulate spin and magnetization through electrical currents, a phenomenon that they’ve dubbed the anomalous Hall torque.

“This is brand new physics, which on its own is interesting, but there’s also a lot of potential new applications that go along with it,” said Eric Montoya, assistant professor of physics and astronomy at the University of Utah and lead author of the study. “These self-generated spin-torques are uniquely qualified for new types of computing like neuromorphic computing, an emerging system that mimics human brain networks.”

The Physics of Spin and Torque

Electrons have minuscule magnetic fields that, like planet Earth, are dipolar—some spins are oriented north (“up”) or south (“down”) or somewhere in between. Like magnets, opposite poles attract while like poles repel. Spin-orientation torque refers to the speed at which the electron spins around a fixed point.

In some materials, electricity will sort electrons based on their spin orientation. The distribution of spin-orientation, known as symmetry, will influence the material’s properties, such as the directional flow of a ferromagnet’s magnetic field.

Symmetry and the Anomalous Hall Torque

Anomalous Hall torque is related to the well-known anomalous Hall effect, discovered by Edwin Hall in 1881. The anomalous Hall effect describes how electrons are scattered asymmetrically when they pass through a magnetic material, leading to a charge current that flows 90 degrees to the flow of an external electric current. It turns out, an analogous process occurs for spin — when an external electrical current is applied to a material, a spin current flows 90 degrees to the flow of electrical current with the spin orientation along the direction of the magnetization.

“It really comes down to the symmetry. The different Hall effects describe the symmetry of how efficiently we can control the spin orientation in a material,” Montoya said. “You can have one effect, or all effects in the same material. As material scientists, we can really tune these properties to get devices to do different things.”

A Triad of Torques for Spintronic Devices

The anomalous Hall torque is an example of an emerging concept in spintronics, known as self-generated spin-orbit torques, that exhibit unique spin-torque symmetries best equipped to support future spintronic devices. Together with the spin Hall torque and the recently identified planar Hall torque, also discovered by a team including coauthors Montoya and Ilya Krivorotov, physicist at UCI, the anomalous Hall torque completes a triad of Hall-like spin-orbit torques. Because the torque triad should be present in all conductive spintronic materials, the authors have coined them “Universal Hall torques.” Their universality will give researchers a powerful tool for developing spintronics devices.

Revolutionary Spintronic Prototypes

Traditional spintronics usually consist of a non-magnetic layer sandwiched between two ferromagnetic materials, like in Magnetoresistive Random Access Memory (MRAM). Spin-torque MRAMs store and manipulate data by injecting a spin-polarized current from one magnetic layer into a second magnetic layer, which flips the spin-orientation of the second magnetic layer. The spin-orientation “up” or “down” can be mapped to the 0s and 1s used for binary data storage. Spin-torque MRAMs can store and access data faster and more efficiently than traditional MRAMS that rely on magnetic fields to flip the flow.

The authors demonstrate that in their device, the spin-orientation could be transferred from a ferromagnetic conductor to an adjacent non-magnetic material, eliminating the need for a second ferromagnetic layer. In fact, the authors built the first-ever spintronic prototype that exploits the anomalous Hall torque effect.

“We utilized anomalous Hall torque to create a nanoscale device known as a spin-torque oscillator. This device can mimic the functionality of a neuron, but is significantly smaller and operates at higher speeds,” said Krivorotov. “Our next step is to interconnect these devices into a larger network, enabling us to explore their potential for performing neuromorphic tasks, such as image recognition.”

Reference: “Anomalous Hall spin current drives self-generated spin–orbit torque in a ferromagnet” by Eric Arturo Montoya, Xinyao Pei and Ilya N. Krivorotov, 15 January 2025, Nature Nanotechnology.
DOI: 10.1038/s41565-024-01819-7

Xinyao Pei, physicist at UCI, was also a coauthor of the study. The National Science Foundation (ECCS-2213690 and DMREF-2324203) supported the research.
